HA Series

The HA- series include proprietary class H plus® (Hybrid Design) technology, has the efficiency of Class-D amplifiers while delivering sound quality similar to Class-A/B amplifiers. It includes an intelligent limiter that safeguards short circuit, DC offset and thermal issues. If an error does occur, the system will automatically reconnect to the speakers load once the problem is resolved.

This series is an ideal solution for professional in the touring industry, Live Performance and Sound Installation, who require exceptional sound reinforcement . With its features and sophisticated circuitry, the HA series ensure reliable and uninterrupted operation, that provides unparalleled sound quality, efficiency and making it an excellent choice for any business setting.

Features :

  • High voltage output for a wide headroom.
  • Efficient Toroidal transformer core for high power induction response.
  • All-steal 2U/3U durable chassis construction.
  • Unobtrusive recessed carrying handles.
  • European and Japanese components ensure optimal result.
  • Powerful and fast response cooling system.
  • Reduced Front panel features individual Gain control for channel, Signal, Clip and Fault/OK LED indicators assists you to monitor amplifier performance.
  • Cooling rear to front forced air flow with twin tunnel variable high speed fans.
  • Intelligent clip limiter to provide High Dynamics at Negligible Distortion levels.
  • Dual, Bridge or Parallel operation.
  • DC current, Thermal over load and continuous Short Circuit Protection on each channel.
Technical Specifications
Model HA-50 HA-60 HA-90
MAX Output Power RMS 1KHz
2 Ohms
4 Ohms
8 Ohms
Bridge @ 4 Ohms
Bridge @ 8 Ohms
2 X 2500W
2 X 1800W
2 X 1050W
5000W
3700W
2 X 3000W
2 X 2300W
2 X 1300W
6000W
4600W
2 X 4500W
2 X 3600W
2 X 1900W
9000W
6800W
Frequency Response
Power Bandwidth +/-0.50dB
15Hz-25kHz
Total Harmonic Distortion
20Hz - 20kHz
<0.05%
Cross Talk
20Hz - 20kHz
=80dB
Input Sensitivity @ 8 1V
Voltage Gain ( Factory  setting ) 38dB
Damping Factor
20Hz - 20kHz
>600
Signal-to-Noise-Ratio
A Weighted
>105dB >110dB
1/8 rated power @ 4 5A 8A 14A
Rack Mount Space 2U
Dimensions / W x H x D (mm)
                    / W x H x D (inches)
19 x 3.5 x 18 19 x 53.5 x 18 19 x 5.5 x 20
Weight 18Kg 21Kg 35Kg
Net / Shipping 19Kg 22Kg 37Kg
Color Skin
